Capacity

FABRICATION


With I&M’s One Source Shop, from concept to final product, we have all you need.

Software

  • Inventer 3D
  • Artube CAD CAM Software
  • Pro Engineer
  • AutoCad 2019
  • SigmaNest CAD CAM Software
  • MetalSoft CAD CAM
  • Shop Data Systems CAD CAM
  • G-Zero CAD CAM
  • Tops100 CAD CAM
  • Tops600 CAD CAM

Laser Cutting

  • Trumpf 5030 10Kw fiber
  • Trumpf 5030 12Kw fiber
  • Trumpf 5030 5Kw fiber
  • Adige Tube Laser LT8 up to 8” square, 3500 watt
  • Adige Fiber Tube Laser LT8.10 up to 8” square, 3000 watt
  • Trumpf 3050 Laser Center, 5,000 watt
  • Trumpf 3040 Laser Center, 5,000 watt
  • Trumpf 4030 Laser Center 1” x 80” x 160” 4,000w
  • 4-Trumpf 3030 Laser Center 5,000 watt



Water Jet Cutting

  • Flow 6012 Water jet with Hyper pressure Tech,5 Axis Head, 72” x 144” table x 8” thickness











Plasma / Flame Cutting

  • 1999-MG High Speed Plasma Cutting Machine with 96″ x 240″ tables, capacity-2″ Plasma & 6″ Flame cutting, Dual Cutting Heads

















Punching / Stamping

  • 1998 Finn Power CNC Turret Punch, 33 Ton, 1/4″ x 60″ x 200″ Capacity with 3 Auto Index Stations
  • Cincinnati OBI Hydraulic, 75 ton
  • Rockfort 200 Ton Straight Side
  • Federal Punch Press, 70 Ton
  • Johnson Punch Press, 55 Ton











Forming

  • (2)T rumpf V320 High Precision 10 Axis CNC 355 Ton, 14’ length, Material Sheet Lifters
  • Trumpf V230 High Precision 8 Axis CNC Press Brake, 255 Ton, 10’ length
  • (2) Trumpf V85 High Precision 8 Axis CNC Press Brake, 90 ton, 7’ length
  • Cincinnati Autoform, 350 ton, 12’ length Cincinnati Auto Shear, Auto front & rear gauging with
  • Cincinnati Auto Shear, Auto front & rear gauging with Auto sheet stacker, 1/4” x 12’ capacity
  • Auto Sheet Stacker, 1/4” x 12’ capacity
  • 8’ Chicago Press Brake, CNC, 40 ton
  • Cincinnati Shear 3/8” x 6’ capacity

Machining

  • Daewoo, Puma 250 CNC Turning Center, 3” bar
  • 2-Daewoo, Puma 300 CNC Turning Center, 4” bar
  • Daewoo, Lynx, 22M CNC Turning Center, Live tooling
  • Mori-Seiki NLX 2500 CNC Turning Center, Live tooling
  • Mori-Seiki SL-3A CNC Turning Center
  • Mori-Seiki CL 25 CNC Turning Center
  • Hardridge Conquest T42





  • Mori-Seiki MV-40 4 Axis CNC Mill, Daul Pallets
  • Mori-Seiki MV-40 4 Axis CNC Mill, MV50 Pallets
  • Mori-Seiki MV-50 4-Axis CNC Mill
  • Mori-Seiki MV-80 4-Axis CNC Mill
  • Fadal 6030-4 Axis CNC Mill
  • Fadal 4020-4 Axis CNC Mill
  • 3-Pratt & Wittney-3 Axis CNC Mill





























  • Hass Tool Room Mill
  • G&L Horizontal Boring Mill
  • C11”V 91.V 2 64” Travel
  • 5’ Radial Arm Drill, 4” Capacity
  • (2) 4’ Radial Arm Drill, 3” Capacity
  • (12) Drill Presses
  • Grob Drill Sharpener
  • Mori-Seiki SH-50 Horizontal Mill, Three Pallets
  • Monarch VMC 150B, 4 Axis CNC, Daul Pallets



Robotic Welding

  • ABB Robotic Welder













Welding

  • Hobart TigWave 350 Amp Tig Welder
  • Hobart Tig Machine, 300 Amp
  • Miller SpoolMate Aluminum Mig Welder, 200 Amp
  • (2) Miller ShopMaster Mig Welder, 300 Amp
  • Miller Aluminum Mig Welder, 250 Amp
  • Electric Arc Metal Desinigrator
  • Termal Arc Pak 5XR Plasma Cutter







  • (2) Miller Mig Wire Welders, 250 Amp
  • (2) Airco Mig Wire Welders, 250 Amp
  • P&H Stainless Mig Wire Welder, 300 Amp
  • Hobart Stick Welder, 300 Amp
  • (2) Airco Portable Stick Welder, 250 Amp
  • Miller Spot Welder, 2.5 KVA
  • Lincoln 110v Portable Welder

.



Sawing

  • Do All C16SA Swivel Automatic Horizontal 10″ x 20″
  • Do All C16A Automatic Horizontal 10″ x 20″
  • Do All C10A Automatic Horizonta l9″ x 12″
  • Do All Hydraulic Tilt Frame, 18″ x 20″
  • DoAll Vertical Hydraulic Saw, 36”
  • DoAll C16 Auto Saw, 10” x 2” capacity
  • Power-Matic Vertical Band Saw, 19”
  • Wells Horizontal Band Saw, 10” x 20”
  • Johnson Horizontal Band saw, 10” x 20” capacity



Grinding

  • Thompson Surface Grinder, 12” x 24” Sunnen Hone













Fabricating

  • Hydraulic IronWorker, 50 Ton
  • Hydraulic IronWorker, 30 Ton
  • Webb Plate Roller, 3/8″ x 48″
  • Sheet Metal Roller, 16 ga x 32″
  • Sheet Metal Roller, 3/16″ x 36″
  • Pipe Notching Machine, 2-1/2″ capacity
  • (2) Oster Threading Machines 2-1/2″ Pipe, 2″ Bolt capacity
  • Pines Tube Bender



Finishing

  • 5 Stage Automatic Powder Coat Line, 48″ x 72″ x 144″ part size capacity
  • Down Draft Paint Booth with Roller Track System
  • Webb, 25 H.P., 36” width
  • Timemsaver 15 H.P., 30” width
  • Glass Bead Blasting Cabinet
  • (3) Parts Tumblers
  • Sandblasting System, 150 CFM
  • VibraDyne vibratory deburring machine
  • (5) Belt Sanders
  • (6) Bench grinders

Material Handling

  • (8) 1/2 Ton Yard Crane
  • (9) 5 Ton Overhead Crane System
  • (9) 2 Ton Overhead Crane Systems
  • (2) 3 Ton Overhead Crane Systems
  • (2) 10 Ton Overhead Crane Systems
  • (33) Fork trucks, 5000 pound capacity







Delivering

  • (1) 1 Ton Dodge delivery truck w/35’ delivery trailer
  • (2) Box trucks, 24’ Internationals
  • (1) Flatbed truck, 24’ International
  • (1) Ford 14’ box truck

.
